Hope this post will be helpful for freshers who does cloning for first time in EBS.
1.
Pre-Clone
- You can take a backup of the files below (Conditional) :
- /u01/app/oracle/ebzd/R122/EBSapps.env (save actual copy, not symlink)
- $CONTEXT_FILE (both tiers)
- $TNS_ADMIN (both tiers)
- $ORACLE_HOME/dbs (exclude any logfiles)
- Create pfile from spfile
- Create controlfile from trace
- - $<Custom_TOP> (All the files under custom top)
Note :
I have commented few items as conditional since they are environment
specific. Please double check whether it actually needed for your environment.
2.
Prepare Source Instance
Check for in-progress online patching cycle:
On the Source system, there should not be any in-progress online
patching cycle. Online
patching should be done till cleanup stage and also fs_clone should be
run to synchronize with
the application file system RUN and PATCH.
You can check it easily by below command:
SQL> select ADOP_SESSION_ID, PREPARE_STATUS, APPLY_STATUS,
FINALIZE_STATUS,
CUTOVER_STATUS, CLEANUP_STATUS, ABORT_STATUS, STATUS, ABANDON_FLAG,
NODE_NAME from AD_ADOP_SESSIONS order by ADOP_SESSION_ID;
Or check with adop -status and
make sure all the phases are completed properly. If any outstanding patch
session, Either complete it or abort before cloning.
2.1 OS and Patch Level
Source and
Target must be on the same Operating System (OS) and patch level
2.2 Check Disk Space on the Source system and Target
Ensure the
Source System has enough free disk space. Oracle Fusion Middleware cloning
tools require 6GB in /tmp and 6GB under $COMMON_TOP. On the target system file
system space should match as that of source.
2.3 AD/TXK Patches
Apply the
latest AD/TXK patches to the Source system.
You can check
the lastet version of source instance by below SQL statement.
SQL> SELECT
abbreviation,codelevel FROM AD_TRACKABLE_ENTITIES WHERE abbreviation in (‘txk’,’ad’);
Output :
ABBREVIA
CODELEVEL
-------- -------------------------
ad C.7
txk C.7
Conditional note :
If we are not on
latest version of AD/TXK patches then we need to apply (Not mandatory step)
Note: Ensure all the services are up in the Source System before
proceeding with the following two
steps
3. Prepare Source Tier
3.1
DB Tier
- You can refresh the db through any of the method as per your
convenient.
- If the db is running already in target server, you can simply drop
the db and refresh database from source.
Methods can be followed for refresh :
- Cold backup
- Hot backup
- Rman backup
Please read these posts for RMAN methods :
RMAN active db duplication
Read
RMAN backup based duplication
Read
3.1.1 Run adpreclone.pl script
cd $ORACLE_HOME/appsutil/scripts/${CONTEXT_NAME}
perl adpreclone.pl dbTier
Note : $CONTEXT_NAME is nothing
but <instance-name>_<hostname>
3.2 Apps Tier
Log on to the
Application node of the Source System as the applmgr user.
Source the
environment file of the Run Edition File system.
$. EBSapps.env
run
Important note :
When you do cloning make to sure to note down the run file system in
the source. If your source has fs1 has the run file system then we must refresh
fs1 as run file system in the target. If source has fs2 in run file system then
we must refresh fs2 as run file system in the target.
For example : If my run file system is in fs2 in source then i would do
the below.
- Make fs2 in target (Run file
system first)
- Make fs1 from fs2 (PAtch file
system)
3.2.1 Run adpreclone.pl
script
Check edition , should run file system
echo
$FILE_EDITION
Execute adpreclone
$cd
$ADMIN_SCRIPTS_HOME
$perl adpreclone.pl appsTier
3.2.2 Tar Application RUN
File system
$. EBSapps.env run
Check edition , should return run file system
echo $FILE_EDITION
$cd
$RUN_BASE
Ex:
/u01/app/oracle/ebz2/R122/fs2
$nohup tar –czvf
ebz2_runfs.tar.gz EBSapps >
ebz2_runfs.log &
Note: Our run file system is
fs2, so we are compressing fs2 directory. Its enough if we only copy EBSapps directory
under run filesystem. Rest of the directories will be created in target through
adcfgclone.
4 Prepare Target System
Backup Context & Config Files (please see Pre Clone steps; you
should have saved off the necessary information then; if not, please do so now)
4.1 Backup files in Target Db Tier/
Take the backup of inti<sid>.ora and $CONTEXT_FILE using “cp” command.
4.2 Backup file in Target APPS Tier CONTEXT_FILE and
custom env file
Take the backup of CONTEXT_FILE and CUSTOM ENV file usins “cp” command.
Note : Make sure both apps and
DB services are down in target instance before proceeding with below steps
5 Cleanup Target Application File System
Remove application directory structure from target application instance
under $RUN_BASE
And $PATCH_BASE in the target application tier system.
$. EBSapps.env
run
bash-3.2$ cd /a01/apps/CLONE/
bash-3.2$ ls
EBSapps.env L2866958.log L2866963.log
fs1 fs2 fs_ne scripts
$ pwd
/a01/apps/CLONE/
$ rm -rf *
Once everything is deleted make a empty directories for run and patch
file system.
mkdir -p /a01/apps/CLONE/fs1
mkdir - /a01/apps/CLONE/fs2
Clean old inventory files from local inventory in application tier.
Please check local inventory location in /etc/oraInst.loc (other wise you will
get error saying oraInventory already exists)
[applmgr@xxxxxxxxxxx ~]$ cat /etc/oraInst.loc
inventory_loc=/u01/app/oracle/ebz2/oraInventory
cd /u01/app/oracle/ebz2/
mv oraInventory oraInventory_old
mkdir oraInventory
Cleanup Target Database File
Drop destination DB (If already DB exists)
$sqlplus / as
sysdba
SQL>
shutdown immediate;
SQL>
startup mount exclusive restrict;
SQL> drop database;
You can also go to the location
where db files present and clear using rm -rf command.
Cleanup DB files in ASM (conditional)
Note : If Target DB files are placed under ASM, we need to connect ASM
and remove control files, Data files and
redo log files.
Go to server xxxxdbxt02
Sudo –iu grid
[grid@xxxxdbxt02 ~]$ cat
/etc/oratab
+ASM2:/u01/app/12.1.0.2/grid:N
# line added by Agent
Use the below to source the env,
+ASM2 – instance name
/u01/app/12.1.0.2/grid – Grid_Oracle_HOME
[grid@xxxxdbxt02 ~]$ . oraenv
ORACLE_SID = [grid] ? +ASM2
The Oracle base has been set
to /u01/app/grid
[grid@xxxxdbxt02 ~]$ asmcmd
ASMCMD> lsdg
It will list the available disk groups, go to releavant disk group and delete
your DB files under Target sid.
ASMCMD> cd DATA/Target_sid
ASMCMD> ls
CONTROLFILE/
DATAFILE/
TEMPFILE/
Go to each directory and execute the below,
ASMCMD> rm –rf *
Performe the following steps if you are not reusing the old OHOME
(Conditional):
Manual DB drop
Delete all the data files from
target database instance. Also check control_file & log_file
Location and remove them too.
Use simple rm –rf command to delete these database files.
Deregister old OHOME (Conditional)
cd $ORACLE_HOME/oui/bin
./runInstaller -silent -detachHome -invPtrLoc /etc/oraInst.loc
ORACLE_HOME="/u01/app/oracle/product/11.2.0.4/ebzd"
Copy oracle_home from the source to target.
Verify Inventory & oratab
entry
4.1 DB Tier Inventory
$cat /etc/oraInst.loc
Note: DB
Inventory is always set to global inventory “/u01/app/oraInventory”
4.2 Oratab entry - - Only
for new instances
$vi
/etc/oratab
Add new
instance oracle home entry
4.3 ADCFGCLONE
Its always recommended to copy
source oracle home to target and run adcfgclone.pl
Clone DB Tier DataBase
Note : For building a new instance
(Oracle_Home), Steps to clone DB oracle_home from source to target given here
11.1 Run adcfgclone in DB
Tier – Only for New Instances/ Oracle Home binaries copied
a) Log on to
the Target Instance as the oracle user(DB binaries owner).
b) Source the
Database tier environment file.
c) Execute the
following commands:
$ORACLE_HOME/appsutil/clone/bin
$perl
adcfgclone.pl dbTechStack
Disable RAC mode (Conditional):
cd $ORACLE_HOME/rdbms/lib
make -f ins_rdbms.mk rac_off
make -f ins_rdbms.mk ioracle
adcfgclone options for DB tier :
adcfgclone.pl dbTier - This option will be used specifically for cold
backup. This option will create and configure oracle home, config files and
database in the target.
adcfgclone.pl dbTechStack - This option will be used mainly if we are
duplicating database thru rman or any other hot backup method. We must need to
manually copy the source oracle home to target. dbTechStack option will create
all the config files (ex : xml file) and configure target oracle home.
11.2 Create context file for
DB – if previous context file is not available (Conditional)
Go to $ORACLE_HOME/appsutil/bin
[oracle@xxxxdbxt02 bin]$ perl adbldxml.pl
Answer the
questions according to your Target DB server and create context file for DB
tier.
4.4 Pre Rman Dupicate
setup:
Copy the backed up init<sid>.ora and CONTEXT FILE to auxiliary
server.
Create a password file in target DB using “orapw” and copy the same in
Auxiliary DB under
$ORACLE_HOME/dbs location
Source the environment using <context_name>.env
Start instance in nomount
Choose any of below RMAN scenario to to restore
- Cold backup
- Hot backup
- Rman backup
6 Post cloning DB activity
6.1 Run EBS Technology
Codelevel Checker (ETCC) In DB Tier
Download the latest version from MOS
sh
checkDBpatch.sh
Enter the
full path to the DB Context file
:/u01/app/oracle/product/11.2.0.4/ebzclone/appsutil/ebzclone_xxxxdbxt02.xml
6.2 Node table clean up
Connect as apps user
Sqlplus
apps/<Source_apps_pwd>
Exec the following :
Select
node_name from fnd_nodes;
It will
display source apps and DB nodes.
Cleanup fnd_nodes table :
Sql>exec
fnd_conc_clone.setup_clean;
Sql>commit;
Select node_name from fnd_nodes;
It will retrun
no rows.
6.3 Edit template for
listener (Conditional)
Edit file:
/u01/app/oracle/product/11.2.0.4/ebzd/appsutil/template/ad8ilsnr.ora
Remove this line:
(ADDRESS = (PROTOCOL = TCP)(HOST =
%s_virtual_hostname%.%s_domainname%)(PORT = %s_dbport%))
Add these lines:
(ADDRESS_LIST =
(ADDRESS = (PROTOCOL = TCP)(HOST =
%s_virtual_hostname%.%s_domainname%)(PORT = %s_dbport%)(IP = FIRST)))
(ADDRESS_LIST =
(ADDRESS = (PROTOCOL = TCP)(HOST = %s_dbhost%)(PORT = %s_dbport%)(IP =
FIRST)))
6.4 Run autoconfig in db
tier
Source
target environment file
Execute
adautocfg.sh
$ORACLE_HOME/appsutil/scripts/$CONTEXT_NAME/adautocfg.sh
Connect as apps user
Sqlplus
apps/<Source_apps_pwd>
Exec the
following :
Select
node_name from fnd_nodes;
It will
display only Target DB node.
Restore wallet information to sqlnet ifile (conditional)
Place Pending jobs on hold (Conditional)
update APPLSYS.FND_CONCURRENT_REQUESTS set HOLD_FLAG = 'Y' where
PHASE_CODE = 'P';
7 APPS Tier Cloning
7.1 Copy APPS Tier Run
File System
Login to
Target application server as applmgr user
Copy the apps
filesystem binaries from source to destination.
Using scp command
Login to Target(ebzclone) application system using applmgr user
$scp –rp
<ad_id>@<src_db_server>:/scratch/ebz2_runfs.tar.gz
/<stage_location>
Note :
We need to copy this zip file under fs2
where we intially directoty.
Using sftp
Login to Target(ebzclone) application system using applmgr user
cd
<stage_location>
ftp
username@<source(ebz2) instance name>
cd /scratch/
mget
ebz2_runfs.tar.gz
After finishing copy of backup,comeout from ftp session by entering
“quit” at command prompt
Create apps filesystem directories – Only for New Instance
$mkdir –p
/u01/app/oracle/ebzclone/R122/fs1 /u01/app/oracle/ebzclone/R122/fs2
Untar apps file system
Note: In destination server Set $RUN_BASE and $PATCH_BASE based on
source run and patch file system.
If run filesystem is fs2 in source instance, set same fs2 as run in destination
instance
and untar.
$export
$RUN_BASE=/u01/app/oracle/ebzclone/R122/fs2
$cd
/u01/app/oracle/ebzclone/R122/fs2
$nohup tar –xvzf /<stage_location>/ebz2_runfs.tar.gz
&
$export PATCH_BASE=
/u01/app/oracle/ebzclone/R122/fs1
Configure Target Apps Tier
Check the oraInst.loc file entry ,it must contain the entry for target
instance
App Tier Inventory
$cat /etc/oraInst.loc
inventory_loc=/u01/app/oracle/ebzclone/oraInventory
inst_group=oinstall
8.1 Run adcfgclone in
Apps Tier
Make sure you are running adcfgclone from the same file system as your
source
For example : If my run file system is in fs2 in source then i would do
the below.
- Make fs2 in target (Run file
system first)
- Make fs1 from fs2 (PAtch file
system)
$ cd /u01/app/oracle/ebzclone/R122/fs2/EBSapp/comn/clone/bin
$ perl adcfgclone.pl appsTier </path/to/XML/file>
If you do not have the XML file, use the following method:
[applmgr@xxxxvebsxd03 bin]$ perl adcfgclone.pl appsTier
Enter the APPS password :
Do you want to add a node (yes/no) [no] :
Target System File Edition type [run] :
Provide the values required for creation of the new APPL_TOP Context
file.
Target System Hostname (virtual or normal) [xxxxVEBSXD03] :
Target System Database SID : ebzclone
Target System Database Server Node [xxxxxxx] : xxxxxx
Target System Database Domain Name [xxxxx.com] : -- Hit Enter
Target System Base Directory : /u01/app/oracle/ebzclone/R122
Target System Base Directory set to /u01/app/oracle/ebzclone/R122
Target System Current File System Base set to
/u01/app/oracle/ebzclone/R122/fs2
Target System Other File System Base set to
/u01/app/oracle/ebzclone/R122/fs1
Target System Fusion Middleware Home set to
/u01/app/oracle/ebzclone/R122/fs2/FMW_Home
Target System Web Oracle Home set to
/u01/app/oracle/ebzclone/R122/fs2/FMW_Home/webtier
Target System Appl TOP set to
/u01/app/oracle/ebzclone/R122/fs2/EBSapps/appl
Target System COMMON TOP set to
/u01/app/oracle/ebzcnv1/R122/fs2/EBSapps/comn
Target System Instance Home Directory [/u01/app/oracle/ebzclone/R122]
: --Hit Enter
Target System Instance Top set to
/u01/app/oracle/ebzcnv1/R122/fs2/inst/apps/ebzclone_xxxxvebsxd03
Do you want to preserve the Display [xxxxvebsxd03:0.0] (y/n) : n
Target System Display [xxxxvebsxd03:0.0] :
Target System Root Service
[enabled] :
Target System Web Administration [enabled] :
Target System Web Entry Point Services [enabled] :
Target System Web Application Services [enabled] :
Target System Batch Processing Services [enabled] :
Target System Other Services [disabled] :
Enter port pool value[0] : 37 (standard port value for ebzclone
instance)
-
-
UTL_FILE_DIR on database tier consists of the following directories.
1. /usr/tmp
2. /archive/ebz/inbound
3. /archive/ebz/outbound
4. /apps9/oracle_cifs_mount/operations/shipping_label
Choose a value which will be set as APPLPTMP value on the target node
[2] :
File system clean-up
After
finishing adcfgclone in run file system,
Run the
correct ENV file
cd
/u01/app/oracle/ebzclone/R122/
. EBSapps.env run
Make sure you
have sourced the run file system
echo
$FILE_EDITION
It should be
RUN
Delete .env
files belong to source(ebz2) instance
cd $APPL_TOP
rm –rf
*ebz2*.env
Copy the Target Run
file system to Patch file system:
Do the below in Target server :
fs2 - run file system
fs1- patch file system
cd
/u01/app/oracle/ebzclone/R122/fs2/
cp –r
EBSapp /u01/app/oracle/ebzclone/R122/fs1/
Note :only
do copy of “EBSapps” directory,No need to copy FMW_Home and inst directories.
Adcfglone
will create those directories
Run adpreclone on
target run file system
Check edition , should
run file system
echo
$FILE_EDITION
Execute adpreclone
$cd
$ADMIN_SCRIPTS_HOME
$perl adpreclone.pl appsTier
Copy run fs to patch
fs
Run adcfgclone on
Patch file System(Target):
cd
/u01/app/oracle/ebzclone/R122/fs1/EBSapp/comn/clone/bin
$echo $CONTEXT_FILE (copy the run file system context file)
$ perl
adcfgclone.pl appsTier
Target System File Edition type [run] : patch
Note : It will
prompt you for a context file,make sure you will give the fullpath of Run file
system
Context
file (DO NOT use the one you saved off,
use the one from the RUN file system)
Location of
Run System Context File: <Full patch to run fs context file>
-
-
Target System Port Pool
[0-99] : 37 if patch is fs1, 38 if patch is fs2
After
finshing adcfgclone start all the services on run file system
cd
/u01/app/oracle/ebzcnv1/R122/fs1/EBSapp/
.EBSapps.env run
echo
$FILE_EDITION
it
should be RUN
cd
$ADMIN_SCRIPTS_HOME
./adstrtal.sh
<apps_username>/<apps_password>
Validate the front end
Login
into the front end using sysadmin user and perform the validate steps and
validate
The application to ensure everything
is fine.
Post cloning activities in R12.2 :
Stop application
services
Go to
$ADMIN_SCRIPTS_HOME
$
./adstpall.sh apps/<apps_pwd>
Reset apps &
other passwords:
Reset sys
& system password:
$sqlplus / as sysdba
SQL>alter profile
APPS_PROFILE limit PASSWORD_VERIFY_FUNCTION null ;
SQL>altyer user sys identified by <newpassword>;
SQL>alter user system identified by <newpassword>;
ALLORACLE
FNDCPASS
apps/<old_password> 0 Y system/system123 ALLORACLE
<newpassword>
SYSADMIN
--> FNDCPASS apps/not2share123 0 Y system/<password> USER sysadmin
<new_password>
APPS-->
FNDCPASS apps/<old_password> 0 Y system/mock2system SYSTEM APPLSYS
<new password>
Note:
Oracle recommends to use AFPASSWD utility to change the passwords over
FNDCPASS.
SQL>alter profile APPS_PROFILE limit PASSWORD_VERIFY_FUNCTION
VERIFYPASSWORD14 ;
Change
Apps password in R12.2.4 (Weblogic Console)
Start
AdminServer using the adadminsrvctl.sh script from your RUN filesystem
Do not
start any other application tier services.
Update the
“apps” password in WLS Datasource as follows:
Log in to
WLS Administration Console.
Click Lock
& Edit in Change Center.
In the
Domain Structure tree, expand Services, then select Data Sources.
On the
“Summary of JDBC Data Sources” page, select EBSDataSource.
On the
“Settings for EBSDataSource” page, select the Connection Pool tab.
Enter the new password in the
“Password” field.
Enter the
new password in the “Confirm Password”
field.
Click
Save.
Click
Activate Changes in Change Center.
Start all the application tier services
using the adstrtal.sh script.
Validate
the changed passwords
Try to
login with changed passwords and validate the functioning
9 FS_CLONE (Conditional)
Run the fs_clone in application instance and make sure it should be
completed without errors.
cd /u01/app/oracle/ebzclone/R122/
.EBSapps.env run
echo $FILE_EDITION
it should be RUN
]$ adop phase=fs_clone
Check the log files for errors if comes and resolve them after that
again run fs_clone
